60138654
SANY
60138654
The SANY 60138654 pump functions as a hydraulic system component for SANY port material handling equipment, including reach stackers and container handling cranes. This OEM replacement part delivers hydraulic fluid flow to support steering systems, lifting mechanisms, and attachment control functions in port and intermodal terminal operations. The pump mounts to the equipment's transmission or engine drive system and operates as part of the machine's hydraulic power circuit.
Designed for direct replacement on SANY port machinery, this pump matches the original equipment specifications for mounting flange dimensions, shaft spline configuration, and port connections. The part supports maintenance and repair operations for port equipment fleets operating in container terminals, inland ports, and logistics yards.
Parameter | Specification |
Part Number | 60138654 |
Product Type | Hydraulic Gear Pump |
Brand | SANY |
Equipment Category | Port Machinery |
Drive Type | Engine / Transmission Driven |
Mounting Method | Flange Mount |
Application | Port Crane and Forklift Hydraulic Systems |
Fluid Type | Hydraulic Oil |
This pump fits the following SANY port machinery models:
SRSC45 series reach stackers
SRST50 series heavy forklifts
SRSC3532 series container handlers
SCP130A port crane equipment
SANY manufactures additional pump variants for other port equipment lines including SRSC1009-6E, SRSC45H1 through SRSC45H9 series, SRSC4535, SRSC4545, SRSC45GC, SRSC3615, SRSC0808, SDJ450FA, and SRSC45V series reach stackers. Buyers should verify their specific part number before ordering, as different equipment generations and configurations use different pump specifications.
