Wheel Loader L956F

Parameter

Rated bucket capacity

3.0 m3(2.7～4.5)

Minimum steering radius (outside of rear wheel)

6325mm

Rated carrying-capacity (kg)

5000

Transverse passing radius (outside of bucket)

7260 mm

Maximum traction force (kN)

165 kN

Altitude (m)

-

Tipping load

≥110 kN

Ambient temperature（℃）

-

Maximum breakout force

≥175kN

Wading depth（mm）

-

Forward I

0~13 km/h

Forward Ⅱ(km/h)

0~38km/h

Forward Ⅲ(km/h)

-

Forward Ⅳ(km/h)

-

Reverse I (km/h)

0~17 km/h

Reverse II

-

Reverse III

-

Reverse IV

-

Dimension

Overall length (mm)

8260

Overall width (mm)

3024

Outside width of wheel

2845 mm

Wheel track

-

Overall height (mm)

3423

wheelbase（mm）

3200

Dumping angle

-45°

Maximum dumping height

3100 mm

Number of axles

2

Corresponding dump reach

1190mm

Maximum lifting height of fork horizontal section(mm)

-

Total mass (kg)

17550

Minimum ground clearance

534 mm

Axis pin at maximum lift height

4125

Wheelbase (front/rear) (mm)

-

-

-

Engine

Engine model/Drive Motor Model

WD10G220E23

Number of cylinders

6

Engine type

In-line、water-cooled 、direct injection、dry sleeve

Bore/stroke

126/130 mm

Engine power (KW)

162

Minimum fuel consumption

≤215g/kw.h

Rated engine speed

2000 r/min

Maximum torque (N.m)/rotation speed (r/min)

980/1500

Displacement (ml)

9726

Emission standard

GB 20891-2007(Country 2)

Transmission system

Type of torque converter

Single-stage four-element twin turbine torque converter

Torque ratio

4.20

Oil cooling mode

Circulating water cooling

Oil pressure of torque converter inlet

0.5~0.6MPa

Oil pressure of torque converter outlet

0.21~0.26MPa

Transmission type

Planetary power shift

Shifting gears

forward 2 reverse 1

Gear ratio of forward I

2.653

Gear ratio of forward Ⅱ

0.711

Gear ratio of forward Ⅲ

-

Gear ratio of forward Ⅳ

-

Gear ratio of reverse I

1.941

Gear ratio of reverse II

-

Gear ratio of reverse III

-

Gear ratio of reverse IV

-

Model of variable-speed pump

LG03-BSB-A

Working pressure of shifting

1.1～1.5 MPa

Main drive type

First reduction of spiral bevel gear

Main drive reduction ratio

4.625

Wheel reduction type

One-stage planetary reduction

Wheel reduction ratio

4.94

Drive type

CHANGCHAI four-wheel drive

Tyre size

23.5-25

Front tyre pressure

0.39±0.01 MPa

Rear tyre pressure

0.33±0.01 MPa

Type of foot brake

Air-over-oil caliper disc brake

Brake pressure (MPa)

0.784 MPa

Parking brake type

Electric air-controlled internal expansion shoe

Steering system

Type of steering system

Load-sensing full hydraulic articulated steering

Model of priority valve

VLE-150S

Steering pump model

100/10

Steering cylinder - bore x rod diameter x stroke

HSGL-90*50*360mm

Steering gear model

Xcel80-800

Steering angle (°)

35°

Working pressure of steering system

16 MPa

-

-

Working equipment

Type of working device

Hydraulic pilot control

Boom cylinder - bore × rod diameter × stroke

HSGF-165×90×805 mm

Turning bucket cylinder - bore x rod diameter x stroke

HSGF-190×90×548mm

Model of working pump

JHP3160S

Displacement of working pump (ml/r)

160

Model of multi-way valve

DFSY-32-18.5

Model of pilot valve

GDXS2-DT

Working pressure of working device hydraulic system

18.5MPa

Bucket lift time (full load)

≤5.8 s

Bucket fall time (no load)

≤3.1 s

Bucket dumping time (no load)

≤1.1 s

Time sum of three items

≤10.0s

Oil filling amount

Diesel filling capacity of fuel tank

260 L

Oil filling capacity of axles (main drive and wheel reducer)

2×26 L

Oil tank filling capacity

240 L

Engine oil filling capacity

20 L

Transmission oil filling capacity

44L

Refueling of antifreeze coolant

55

Oil filling capacity of braking system

4 L

-

-
