WHEEL LOADER RIM 4110002508

Specifications

25.00/4.0-25 (Compatible with 750/65R25 tubeless tires)

Structure

5-piece, wide groove, thickened (dedicated for 8-ton machines, wider and stronger than 5-ton machines)

Bolts

16 holes × M24, PCD 380mm (5-ton machines use 12 holes × M22, not interchangeable)

Material

Q345B high-strength steel, load capacity ≥35kN/wheel

Compatibility

Lingong L989F (standard), some 8-ton mining machines

Interchange Part Numbers

4110002907, 4110003110 (same specification replacement)

Key Difference Between L989F and 5-ton Machine (e.g., L956F) Rims

Size

L989F is 25.00/4.0-25; 5 The 1-ton engine uses 25.00/3.5-25 (narrower) rims.

Bolts

L989F 16×M24; 5-ton engine 12×M22 (different number of holes/bolt specifications, not interchangeable).

Tires

L989F with 750/65R25; 5-ton engine with 23.5-25 (different tire width/diameter).

In short

4110002508 is a 25-inch wide grooved rim specifically for the Lingong L989F (8-ton) engine, with 16 holes and M24, and is not compatible with the 5-ton engine.
