0636 010 089 | 六角头螺栓 M8×50 DIN931 8.8 Bolt | 0750 112 140 | 异形密封环 Shaped sealing ring |
4644 231 171 | 油标尺组件 Oil dipstick set | 0732 041 183 | 压力弹簧 Pressured spring |
4642 331 056 | 挡板 Backing plate | 4642 308 083 | 导向环 Guiding ring |
4644 301 016 | 盖板 Cover plate | 0630 531 346 | 挡圈 Sprag |
0636 015 289 | 螺栓 M8×16 DIN933 8,8 Bolt | 4642 308 084 | 导向环 Guiding ring |
0636 305 016 | 螺塞 AM22×1,5 DIN7604 Plug screw | 0750 115 182 | 滚针轴承 35×42×20 Needle bearing |
0634 801 074 | 垫圈 A22×27 DIN7603 Washer | 0730 513 610 | 弹性挡圈 Flexible sprag |
0750 131 053 | 旋装滤油器 Screw-in oil filter | 0635 303 204 | 滚针轴承 F4042 40×47×20 Bearing |
4644 351 076 | 轴 Shaft | 0730 513 611 | 弹性挡圈 Flexible sprag |
0634 313 536 | O型圈 O-ring | 0769 124 115 | 弹性挡圈 Flexible sprag |
0734 401 106 | 搭扣密封环 Hasp sealing ring | 0730 150 779 | 承磨垫 Bearing pad |
0636 610 014 | 螺柱 M8×18 DIN939 8,8 Stud | 0730 109 643 | 垫片 Shim |
0637 006 018 | 螺母 M8 DIN934 8 Nut | 4644 308 859 | 齿轮 Gear |
0769 120 468 | 调整垫片 Regulating shim | 0750 115 109 | 滚针组 45×53×27,8 Needle set |
0730 150 759 | 承磨垫 Bearing shim | 零件号 Part No. | 名 称 及 规 格 Description |
4644 303 529 | 止动垫片 Stopping shim |
4644 308 622 | 齿轮 Gear | 0750 119 048 | 滚柱 Pin roller |
4644 308 265 | 止动垫圈 Stopping washer | 4644 253 045 | 离合器外壳 Clutch casing |
0730 150 773 | 承磨垫 Bearing shim | 0501 309 329 | 外摩擦片 Ex. frictional disc |
0750 119 100 | 滚子组 35,2×55,2×37 Roller set | 4642 308 330 | 内摩擦片 In. frictional disc |
4644 308 266 | 垫圈 Washer | 4642 308 332 | 内摩擦片 In. frictional disc |
4644 308 071 | 承压板 Pressure plate | 4642 308 331 | 内摩擦片 In. frictional disc |
4644 351 070 | 活塞 Piston | 0769 129 011 | 内摩擦片 In. frictional disc |
0750 112 139 | 异形密封环 Shaped sealing ring | 0501 309 329 | 外摩擦片 Ex. frictional disc |
4644 351 094 | 止动片 Stopping disc | 4642 308 330 | 内摩擦片 In. frictional disc |
4642 308 555 | 止动片 Stopping disc | 4642 308 332 | 内摩擦片 In. frictional disc |
0750 112 140 | 异形密封环 Shaped sealing ring | 4642 308 331 | 内摩擦片 In. frictional disc |
0732 041 183 | 压力弹簧 Pressured spring | 0769 129 011 | 内摩擦片 In. frictional disc |
4642 308 083 | 导向环 Guiding ring | 4644 311 005 | 取力器轴 P.T.O shaft |
0630 531 346 | 挡圈 Sprag | 0750 116 259 | 球轴 6209 N/C3 Ball shaft |
4642 308 084 | 导向环 Guiding ring | 0630 503 011 | 轴用弹性挡圈 Flexible sprag for shaft |
0635 303 203 | 滚针轴承 F3526 35×42×26 Bearing | 0630 501 033 | 轴用挡圈 45×1,75 DIN471 Sprag |
0730 513 610 | 弹性挡圈 Flexible sprag | 4644 311 214 | 纸垫 Gasket |
0635 303 205 | 滚针轴承 F4026 40×47×26 Bearing | 0636 015 077 | 螺栓 M8×20 DIN933 8,8 Bolt |
0730 513 611 | 弹性挡圈 Flexible sprag | 4644 311 067 | 输出箱体轮毂 Output housing hub |
0769 124 126 | 弹性挡圈 Flexible sprag | 4644 311 007 | 传动齿轮 Transmission gear |
0730 150 779 | 承磨垫 Bearing shim | 0630 513 068 | 轴用弹性挡圈 Flexible sprag for shaft |
4644 351 012 | 齿轮 Gear | 0635 303 104 | 滚针轴承 HK4516 45×52×16 Bearing |
零件号 Part No. | 名 称 及 规 格 Description | 0630 513 016 | 孔用弹性挡圈 Flexible sprag for hole |
4644 311 913 | 过渡盘 Transition disc |
0630 502 037 | 孔用挡圈 75×2,5 DIN472 Sprag | 4644 311 911 | 纸垫 Gasket |
0769 120 556 | 调整垫片 Regulating shim | 4644 355 864 | 取力器轴 P.T.O shaft |
0735 358 132 | 滚柱轴承 45×75×28 Bearing | 4644 311 008 | 传动齿轮 Transmission gear |
0501 308 830 | 挡圈 Sprag | 0630 513 068 | 轴用弹性挡圈 Flexible sprag for shaft |
0750 116 100 | 球轴承 6009MAC3 45×75×16 Bearing | 0635 303 104 | 滚针轴承 HK4516 45×52×16 Bearing |
