Structural Composition:
Brass valve body, throttling main body, precision throttling orifice
External temperature sensor + capillary tube (attached to the evaporator outlet pipe)
Sealing diaphragm, adjusting spring, standard inlet and outlet connectors
Integrated mounting clips for direct installation into the evaporator housing
Material Advantages:
All-copper valve body is pressure-resistant and vibration-resistant, preventing leakage at high and low temperatures on construction sites
Capillary tube is resistant to bending and breakage, highly sensitive to temperature, and accurately regulates refrigerant flow
Sealing gasket is resistant to refrigerant corrosion, preventing refrigerant leakage
III. Core Functions (Core throttling element of the air conditioning refrigeration system)
Throttling and Pressure Reduction: High-pressure liquid refrigerant passes through a small valve orifice, reducing pressure and temperature, becoming a low-temperature, low-pressure gas-liquid mixture that is then sent to the evaporator. 4190002757; Automatic flow regulation: The temperature sensor collects the evaporator outlet temperature and automatically adjusts the valve opening to match different cooling loads; Compressor protection: Controls the refrigerant flow in the evaporator to prevent liquid refrigerant backflow from impacting the compressor (liquid slugging damage); Indispensable to the entire refrigeration cycle, installed inside the evaporator inlet.
IV. Complete 7-piece set of cooling and heating air conditioning
4130002453 A/C Condenser
4190002822 Thermal Expansion Valve
4190002757 Evaporator Assembly
4190002843 Evaporator Blower Fan
4130002629 A/C Wiring Harness
4190002826 Heater Core
4190002822 Evaporator Housing
