Views: 7 Author: Site Editor Publish Time: 2022-08-31 Origin: Site
SDLG VRT200 Transmission Parts
| VRT200 Transmission Parts Requirement | ||||||||
| Application:SDLG L958F Loader | ||||||||
| SL No | Part Number | Description | Qty | Comparment | 名称 | 小计 | 单重 | |
| 1 | 29050013721 | Gasket | 1 | Gear selector valve | 垫片 | 0.01 | ||
| 2 | 29050013691 | Gasket | 1 | Gear selector valve | 垫片 | 0.01 | ||
| 3 | 29050015193 | Gasket | 1 | control valve | 密封垫 | 0.1 | ||
| 4 | 4030000807 | O-Ring | 2 | PTO | O形圈 | 0.02 | ||
| 5 | 29050013781 | Gasket | 1 | TC Case | 垫片 | 0.01 | ||
| 5 | 29050013151 | Gasket | 1 | Lubricating valve | 密封垫 | 0.01 | ||
| 7 | 29050013331 | Gasket | 2 | Oil stainer | 密封垫 | 0.01 | ||
| 8 | 4030000816 | O-Ring | 1 | Transmission assembly | O形圈 | 0.01 | ||
| 9 | 4030000810 | O-Ring | 5 | Transmission assembly | O形圈 | 0.01 | ||
| 10 | 4041001458 | O-Ring | 1 | Transmission assembly | O形圈 | 0.01 | ||
| 11 | 29050016101 | Gasket | 1 | Gear Changing unit | 密封垫 | 0.02 | ||
| 12 | 29050016121 | Gasket | 1 | Gear Changing unit | 密封垫 | 0.03 | ||
| 13 | 4030000814 | O-Ring | 1 | Drive shaft | O形圈 | 0.02 | ||
| 14 | 4030000596 | Sealing ring | 1 | Output shaft | 油封 | 0.3 | ||
| 15 | 4030001340 | Sealing ring | 1 | Output shaft | 密封圈 | 0.08 | ||
| 16 | 4030000812 | O-Ring | 1 | Output shaft | O形圈 | 0.03 | ||
| 17 | 4030000813 | O-Ring | 1 | Output shaft | O形圈 | 0.1 | ||
| 18 | 4030000211 | O- Ring | 4 | Pressure reducing valve | O形圈 | 0.01 | ||
| 19 | 4130001299 | Pressure switch | 1 | Shift mechanisum system | 压力开关 | 0.2 | ||
| 20 | 29050013911 | Piston Rings | 3 | K12 Clutch Shaft | 活塞环 | 0.04 | ||
| 21 | 29050013851 | Pressure Disc | 1 | K12 Clutch Shaft | 受压盘 | 0.9 | ||
| 22 | 29050015511 | Friction Disc | 4 | K12 Clutch shaft | 从动摩擦片 | 0.25 | ||
| 23 | 29050013861 | Friction Disc | 6 | K12 Clutch shaft | 主动摩擦片 | 0.2 | ||
| 24 | 29050013871 | Friction Disc | 2 | k12 Clutch shaft | 从动摩擦片 | 0.2 | ||
| 25 | 29050014571 | Piston Ring | 2 | K12 Clutch shaft | 活塞环 | 0.1 | ||
| 26 | 29050014561 | Piston Ring | 2 | K12 Clutch shaft | 活塞环 | 0.1 | ||
| 27 | 29050014141 | Clutch Hub | 1 | K12 Clutch shaft | 离合器轮毂 | 0.8 | ||
| 28 | 29050014531 | Piston | 1 | K12 Clutch Shaft | 活塞 | 0.7 | ||
| 29 | 4030000821 | O-Ring | 1 | K12 Clutch Shaft | O形圈 | 0.02 | ||
| 30 | 29050014061 | retaining ring | 1 | K12 Clutch shaft | 挡圈54 | 0.1 | ||
| 31 | 29050013911 | Piston Rings | 3 | K34 Clutch Shaft | 活塞环 | 0.04 | ||
| 32 | 29050014101 | Piston Rings | 2 | K34 Clutch Shaft | 活塞环 | 0.02 | ||
| 33 | 29050014091 | Piston Rings | 2 | K34 Clutch Shaft | 活塞环 | 0.02 | ||
| 34 | 29050013971 | Piston Rings | 2 | K34 Clutch shaft | 活塞环 | 0.01 | ||
| 35 | 4030000808 | O-Ring | 1 | K34 Clutch Shaft | O形圈 | 0.01 | ||
| 36 | 29050014001 | Piston Rings | 2 | KFR Clutch Shaft | 活塞环 | 0.1 | ||
| 37 | 29050013971 | Piston Rings | 2 | KFR Clutch Shaft | 活塞环 | 0.01 | ||
| 38 | 4030000820 | O-Ring | 1 | KFR Clutch Shaft | O形圈 | 0.02 | ||
| 39 | 29050013911 | Piston Rings | 3 | KFR Clutch Shaft | 活塞环 | 0.04 | ||
| 40 | 4021000161 | Bearing | 2 | K12&K34 Clutch Shaft | 轴承 | 1.8 | ||
| 41 | 4021000163 | Bearing | 1 | K34 Clutch Shaft | 轴承 | 2.4 | ||
| 42 | 29050013811 | Shim | 1 | k12 Clutch Shaft | 止推垫片 | 0.08 | ||
| 43 | 29050014041 | Shim | 2 | K12 Clutch Shaft | 止推垫片 | 0.03 | ||
| 44 | 29050013931 | Shim | 1 | K12 Clutch Shaft | 止推垫片 | 0.02 | ||
| 45 | 4110000628 | Bearing | 2 | K12 Clutch Shaft | 轴承 | 0.08 | ||
| 46 | 29050014431 | Gear | 1 | k12 Clutch Shaft | 齿轮总成 | 6 | ||
| 47 | 29050013971 | Piston Rings | 2 | K12 Clutch Shaft | 活塞环 | 0.01 | ||
| 48 | 4030000827 | O-Ring | 1 | Gear Changing unit | O形圈 | 0.02 | ||
