SDLG L956F LG936L SPARE PARTS LIST
1 | water pump | 4110000924103 | 2 | 35*20*30 | WD10 ENGINE USING. CAST IRON |
2 | gasket | 4110000556155 | 5 | 20*12*2 | Low carbon steel plate and rubber |
3 | bushing | 4110000556107 | 6 | 5*2*3 | Tin phosphor bronze ZCuSn10P1 copper sleeve |
4 | connecting rod | 4110000924087 | 6 | 26*10*3 | Steel |
5 | gear ring | 4110000556043 | 5 | 50*50*4 | 136 teeth Iron |
6 | lubricating oil pump | 4110000556003 | 2 | 40*40*10 | 48mm width Single-stage |
7 | flange | 2905002154 | 2 | 15*15*8 | 19 teeth 8 hole |
8 | secondary shaft | 7200000462 | 10 | 50*50*40 | 52 Teeth 50Mn 40Cr |
9 | drive shaft gear | 3030900177 | 1 | 38*22*12 | 19 teeth 50Mn 40Cr XG 2020-06-20-X |
10 | drive shaft gear | 3030900178 | 1 | 18*15*9 | 39 TEETH LG 2021-09-14 XRF-BC |
11 | drive shaft gear | 2905001270 | 5 | 30*15*15 | 39 TEETH LG953-2022-03-15 XRF -BC-40Z |
12 | gear | 2905003322 | 5 | 22*18*9 | 52 Teeth 50Mn 40Cr |
13 | gear pump | 4120005410 | 3 | 25*25*10 | LG03-BSB-A |
14 | control valve | 4120000064 | 3 | 40*25*10 | LG03-BSF |
15 | filter insert | 4110003167001 | 15 | 30*12*12 | QF60M33G-2-001 |
16 | oil filter | 2030900065 | 10 | 18*10*10 | iRON FUEL NET |
17 | friction disc | 2030900028 | 100 | 29*29*2 | 57 TEETH Powder metallurgy materials |
18 | friction disc | 3030900140 | 100 | 27*27*2 | 16 teeth Iron |
19 | piston | 2905002259 | 5 | 35*35*13 | cast iron |
20 | clutch cyclinder | 3030900145 | 5 | 30*30*12 | cast iron |
21 | planet carrier | 2905002343 | 1 | 25*25*15 | 60 TEETH LG2021010383 |
22 | piston | 2905003217 | 5 | 25*25*14 | cast iron |
23 | friction disc | 2030900020 | 20 | 29*29*2 | 6 HOLE 12 SMALL HOLE |
24 | friction disc | 3030900106 | 20 | 27*27*2 | 16 teeth Iron |
25 | controlmechanism | 4110003497 | 4 | 50*50*15 | L955F-1 |
26 | needle roller | 4090000311 | 1000 | 1*1*0.5 | GB309-4*40-GCr15 |
27 | spacer sleeve | 2905002349 | 100 | 5*5*1 | iron plate |
28 | shim | 2905002046 | 100 | 5*5*1 | 10mm size |
29 | retaining ring | 2905002265 | 100 | 5*5*1 | 10mm size |
30 | sealing ring | 4030000146 | 20 | 20*20*2 | HG4-692-SG170*200*15 |
31 | sealing ring | 4110002791 | 20 | 20*20*2 | FB17020012-DWS |
32 | crown wheel | 2907001260/2907001261 | 5 | 45*45*15 | Ratio 7/37 teeth |
33 | propeller shaft | 4110003071 | 2 | 143*21*27 | C52*1404 |
34 | propeller shaft | 4110004221 | 2 | 16*12*12 | P41*409.5 |
35 | link yoke | 4110002066002 | 2 | 12*12*8 | 1491.707-2201062-J |
36 | link yoke | 2908000102006 | 2 | 12*12*8 | XGZL50.5.00-01-D |
37 | gear pump | 4120002513 | 2 | 20*20*30 | 6teeth JHP3160S |
38 | Seal kit of lifting cylinder assembly | 4120006628004 | 20 | 20*20*5 | RUBBER |
39 | seal kit of steering cylinder | 4120006629007 | 20 | 20*20*5 | RUBBER |
40 | seal kit of tilt cylinder assembly | 4120007867004 | 20 | 20*20*5 | RUBBER |
41 | Weld pin | 4043001506 | 2 | 13*9*2 | LGB301-95*130*240-1000Y |
42 | Weld pin | 4043000728 | 2 | 11*8*2 | LGB301-85*115*210/2G-40Cr |
43 | Weld pin | 4043001422 | 2 | 11*21*5 | LGB301-110*212*405-1300Y |
44 | Weld pin | 4043001507 | 10 | 9*13*24 | LGB301-85*130*240-1000Y |
45 | Weld pin | 4043000173 | 10 | 8*14*26 | LGB301-80*140*260-40Cr |
46 | Weld pin | 4043001505 | 10 | 8*14*26 | LGB301-85*142*265-1000Y |
47 | bushing | 4043001508 | 10 | 8*9*8 | LGB302-85*95C2 |
48 | bushing | 4043000026 | 10 | 8*9*8 | LGB302-80*90A2 |
49 | bushing | 4043000467 | 4 | 11*8*8 | LGB302-110*80C1 |
50 | bushing | 4043000439 | 2 | 8*8*8 | LGB302-85*80C2 |
51 | bushing | 4043000752 | 2 | 9*11*9 | LGB302-95*104C2 |
52 | diverter valve | 4120006231 | 1 | 25*15*15 | Xcel80-800 |
53 | air filter element | 13023273 | 20 | 21*21*39CM | 21*21*39CM |
54 | air filter element | weichai duezt 2440 | 20 | 24*24*40CM | 24*24*40CM |
55 | air filter element | LG 50CN 1678 | 20 | 26*26*40CM | 26*26*40CM |
56 | air filter element | cummins 50 CN 545007 | 20 | 25*25*40CM | 25*25*40CM |
57 | cover | 2904000834 | 5 | 40*40*14 | cast iron |
58 | turbine | 2904001243 | 5 | 45*45*13 | Aluminum Iron Bronze |
59 | wheel | 2904000842 | 5 | 25*25*10 | Aluminum Iron Bronze |
60 | WD10G 220E23 | cylinder liner | 5 | 45*35*39 | aluminum alloy /Alloy cast iron |
cylinder piston | |||||
piston ring | |||||
retaining ring | |||||
piston pin | |||||
61 | cumins 6LT9.3 | cylinder liner | 5 | 45*35*39 | aluminum alloy /Alloy cast iron |
cylinder piston | |||||
piston ring | |||||
retaining ring | |||||
piston pin | |||||
62 | WP6G125E28 | cylinder liner | 5 | 45*35*39 | aluminum alloy /Alloy cast iron |
cylinder piston | |||||
piston ring | |||||
retaining ring | |||||
piston pin | |||||
63 | L956F BLADE | 29170042171/29170042161 | 6 | 155*40*49 | Nickel-chromium alloy material |
64 | Valve | 4120000084 | 5 | 22*12*12 | ST-50G |
65 | Fan | 41100015255002 | 2 | 65*65*10 | iron |
66 | fuel filter insert | 4110000189031 | 10 | 10*8*8 | Stainless steel |
67 | sealing ring | 4110000054100 | 5 | 10*10*1 | rubber |
68 | gasket | 4110000057003 | 30 | 12*17*1 | Low carbon steel plate and rubber |
69 | oil filter | 4110000054305 | 50 | 25*10*10 | Stainless steel |
70 | fuel filter | 7200002385 | 20 | 25*10*10 | Stainless steel |
71 | air filter insert | 4110002852014 | 10 | 24*24*44 | Nanofiber material |
72 | oil pump | 411000054083 | 4 | 18*13*8 | 2702 /9J07180121 |
73 | torque converter as | 936 torque conveter Core components | 3 | 45*45*37 | Cast iron |
74 | cover | 4110000194001 | 2 | 40*40*14 | YJSW315-2A-00002 |
75 | turbine | 4110000160072 | 2 | 45*45*13 | YJSW315-2A-10000 |
76 | stator | 4110000160040 | 2 | 25*25*10 | YJSW315-2A-00006 |
77 | filter insert | 4110000507007 | 10 | 15*10*10 | Stainless steel |
78 | drive shaft gear | 3030900094 | 10 | 26*15*15 | 39 TEETH LG953-2022-03-15 XRF -BC-40Z |
79 | gear pump | 4120000063 | 5 | 25*25*10 | LG03-BSB-A |
80 | control mechanism | 4110001680 | 3 | 50*50*15 | LG4110001680/43478/2202190386 |
81 | control cable | 4110001680009 | 5 | 110*1*1 | LGHR936L0002 |
82 | brake caliper | 4120001739 | 4 | 30*20*20 | CAST IRON |
83 | brake disc | 3090900004 | 2 | 48*48*50 | CAST IRON |
84 | sealing ring | 4030000046 | 10 | 18*16*1 | HG4-692-PD130*160*12 |
85 | cyclinder piston | 4120001739009 | 200 | 8*8*6 | JS-ZL50-007 |
86 | sealing ring,dust cover,retaining ring | sets seal for brake: including (4120001739052 + 4120001739053 +4120001739055) | 100 | 15*15*2 | Rubber and steel |
87 | brake plate | 4120001739016 | 200 | 22*12*2 | Material de fricción pulvimetalúrgico |
88 | sealing kit of boom cyclinder | 4120005979001 | 30 | 15*15*2 | 24A103060S |
89 | sealing kit | 4120008483012 | 15 | 15*15*2 | 24A104640S |
90 | connecting rod | 2915000456 | 1 | 80*10*10 | Cast Iron |
91 | bushing | 4043000218 | 10 | 8*8*8 | LGB302-60*58A2 |
92 | bushing | 4043000121 | 4 | 8*8*8 | LGB302-60*50A2 |
93 | bushing | 4043000124 | 5 | 12*8*8 | LGB302-85*125A2 |
94 | bushing | 4043000123 | 2 | 10*10*5 | LGB302-65*80A2/LGB302-65*80B2 |
95 | weld pin | 4043000112 | 5 | 6*9*17 | LGB301-60*95*170-40Cr |
96 | pin | 4043000660 | 2 | 8*14*25 | LGB301-85*132*245/2-40Cr |
97 | weld pin | 4043000725 | 4 | 6*8.5*15 | LGB301-60*85*150/2G-40Cr |
98 | gear pump | 4120001058 | 2 | 20*20*35 | CBGj3100/1010-XF |
99 | spherical plain bearing | 4021000199 | 2 | 10*10*5 | GB9163-GE40ES |
100 | sealing kit of steering cyclinder | 4120005977001 | 8 | 15*15*5 | 24A103070S |
101 | Roller bearing | 4021000134 | 8 | 15*15*6 | GB297-32212 |
102 | pin | 2925001571 | 4 | 15*8*7 | CAST IRON |
103 | set of the pin | LG936L set of the pin OLD | 4 | 40*25*15 | CAST IRON |
104 | pin | 2925000404 | 4 | 15*8*7 | CAST IRON |
105 | spherical plain bearing | 4021000042 | 4 | 10*10*5 | GB9163-GE60ES-2RS |
106 | set of the pin | LG936L set of the pin OLD | 4 | 40*25*15 | CAST IRON |
107 | weld pin | 4043000205 | 2 | 6*12*23 | LGB301-60*125*235G-40Cr |
108 | pin | 2925001270 | 2 | 6*12*24 | LGB301-65*125*235-1000G |
109 | weld pin | 2925001972 | 4 | 6*12*24 | LGB301-65*125*235-980G |
