| P/N: | |
|---|---|
| MODEL : | |
| Size: | |
| weight: | |
| Quantity: | |
L918
SDLG
L0180N3215A36E0
65.5KW
1.0-1.4m³
6700KG
| Technical parameter | |
| Model | L918 |
| Order No: | L0180N3215A36E0 |
| Bucket capacity(m³) | 1.0(1.0-1.4) |
| Operating weight(kg) | 6700 |
| Rated load(kg) | 1800 |
| Rated power(kW) | 65.5 |
| Length×Width×Height(mm) | 5790x2140x2920 |
| Wheel base(mm) | 2260 |
| Max.dumping height(mm) | 2510 |
| Dumping distance(mm) | 920 |
| Steering angel(°) | 35 |
| Engine Model | Yunnei YN4EL089-33CR |
| Emission standard | China Phase III |
| Max.tractive force(kN) | 56 |
| Max.breakout force(KN) | 58 |
| Gears() | Forward 2 reverse 2 |
| Total time(s) | 9.1 |
| Fuel tank capacity(L) | 120 |
| Technical parameter | |
| Model | L918 |
| Order No: | L0180N3215A36E0 |
| Bucket capacity(m³) | 1.0(1.0-1.4) |
| Operating weight(kg) | 6700 |
| Rated load(kg) | 1800 |
| Rated power(kW) | 65.5 |
| Length×Width×Height(mm) | 5790x2140x2920 |
| Wheel base(mm) | 2260 |
| Max.dumping height(mm) | 2510 |
| Dumping distance(mm) | 920 |
| Steering angel(°) | 35 |
| Engine Model | Yunnei YN4EL089-33CR |
| Emission standard | China Phase III |
| Max.tractive force(kN) | 56 |
| Max.breakout force(KN) | 58 |
| Gears() | Forward 2 reverse 2 |
| Total time(s) | 9.1 |
| Fuel tank capacity(L) | 120 |
